Parameter Characteristic Application Videos
Technical parameter
Model | FX2N21-18-4AD-4DA |
External dimensions | Length, width, and height：160*135*20mm |
Power supply | DC24V >1A |
Switching input | 21 channels DC24V NPN/PNP input |
Switching output | 18 channels DC24V PNP output |
Analog input | 4 channels 0-5V |
Analog output | 4 channels 0-5V |
Communication methods | 1 channel RS232 MODBUS-RTU |
Product features：
Model: FX2N21-18-4AD-4DA
External dimensions: length, width, height: 160 * 135 * 20mm
Power supply: DC24V>1A
Switching input: 21 DC24V NPN/PNP inputs
Switching output: 18 DC24V PNP outputs
Analog input: 4 channels 0-5V
Analog output: 4 channels 0-5V
Communication method: 1 RS232 MODBUS-RTU
Previous：PLC SPX2N11-8T-2AD-2H Next：没有了
