Product Introduction
The environmental protection material instrument is a new generation of dedicated data collector for environmental monitoring and pollution source monitoring. It is designed according to industrial standards and has been specially optimized for various requirements of environmental monitoring. It is equipped with rich and complete communication interfaces, supports wired Ethernet, wireless 4G, etc., and meets the requirements for remote communication in different environments. Equipped with rich acquisition and control ports, there are 8 isolated RS232, 4 isolated RS485, 16 high-precision analog signal acquisition, 8 isolated switch signal acquisition, and 8 relay outputs.

Technical parameter

1. 8 channels RS232 interface with isolation, with a baud rate range of 1200-115200;

2. 4 channels RS485 with isolation, baud rate range 1200-115200;

3. 16 channels analog input, 16 bit resolution, supporting 4-20mA input;

4. 8 channels switch input with isolation;

5. 8 channels relay output;

6. One channel high-speed USB 2.0;

7. Built in 4G communication module and built-in WiFi communication module. Equipped with a large capacity lithium battery, supporting charging, and a high-precision clock chip;

8. 10 o'clock one inch touch screen with 16GB of memory space.

9. Running Linux operating system for remote maintenance

Power supply: 220VAC, 50HZ;

Power: 30W;

Weight: 8.5kg;

External dimensions: 400 x 320 x 100
